21000S-16ER

#0 TA STUB HOLDER ER-16

T-A® Holder

See Additional Technical Information

Product Specifications

Series	0
Minimum diameter mm	12.98
Maximum diameter mm	17.67
Length Type	Stub
Flute Type	Straight
Overall length mm	75.34
Tool Reference Length mm	50.80
Body length mm	48.08
Drill depth mm	41.25
Shank type	ER16 Collet
Deep Hole Guidelines	No
Type of Product	Replaceable Drill Body
Product Application	General Purpose

Ordering Information

Package Qty	1
Min. Order Qty	1
Weight in lbs (each)	0.14
Category	Stocked
