| Series | Y |
| Minimum diameter inch | 0.3740 |
| Maximum diameter inch | 0.4369 |
| Length Type | Short |
| Flute Type | Straight |
| Overall length inch | 6.312 |
| Tool Reference Length inch | 3.464 |
| Body length inch | 2.031 |
| Drill depth inch | 1.075 |
| Shank type | Morse Taper |
| Shank diameter inch | #2 MT |
| Pipe tap side inch | 1/16 NPT |
| Deep Hole Guidelines | No |
| Type of Product | Replaceable Drill Body |
| Product Application | General Purpose |
