24020H-004M
#2 TA STD HLDR METR TAPR SHK
T-A® Holder





See Additional Technical Information

Product Specifications
Series2
Minimum diameter mm24.41
Maximum diameter mm35.06
Length TypeStandard
Flute TypeHelical
Overall length mm375.44
Tool Reference Length mm261.52
Body length mm215.90
Drill depth mm199.39
Shank typeMorse Taper
Shank diameter mm#4 MT ISO
Pipe tap side inch1/8
Pipe tap side mm1/8 BSPT
Deep Hole GuidelinesNo
Type of ProductReplaceable Drill Body
Product ApplicationGeneral Purpose
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)2.71
CategoryStocked
