24050H-005M
#5 TA STD HLDR METR TAPR SHK
T-A® Holder





See Additional Technical Information

Product Specifications
Series5
Minimum diameter mm62.38
Maximum diameter mm89.09
Length TypeStandard
Flute TypeHelical
Overall length mm531.80
Tool Reference Length mm388.92
Body length mm317.50
Drill depth mm286.28
Shank typeMorse Taper
Shank diameter mm#5 MT ISO
Pipe tap side inch1/2
Pipe tap side mm1/2 BSPT
Deep Hole GuidelinesNo
Type of ProductReplaceable Drill Body
Product ApplicationGeneral Purpose
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)17.39
CategoryStocked
