240Y0S-075L

#Y TA STD HLDR 3/4"SS

T-A® Holder

Siehe zusätzliche technische Daten

Produktspezifikationen

Series	Y
Minimum diameter inch	0.3740
Maximum diameter inch	0.4369
Length Type	Standard
Flute Type	Straight
Overall length inch	5.531
Tool Reference Length inch	3.246
Body length inch	3.156
Drill depth inch	2.205
Shank type	Lathe
Shank diameter inch	3/4
Shank length inch	2.375
Pipe tap rear inch	1/8 NPT
Deep Hole Guidelines	No
Type of Product	Replaceable Drill Body
Product Application	General Purpose

Bestellinformationen

Packmenge	1
Mindestbestellmenge	1
Jeweiliges Gewicht in Pfund (lbs)	0,36
Kategorie	lagernd
