Series | 5 |
Minimum diameter inch | 2.4560 |
Maximum diameter inch | 3.5079 |
Length Type | Extended |
Flute Type | Straight |
Overall length inch | 24.000 |
Tool Reference Length inch | 20.250 |
Body length inch | 20.000 |
Drill depth inch | 17.850 |
Shank type | Lathe |
Shank diameter inch | 2 |
Shank length inch | 4.000 |
Pipe tap rear inch | 1/2 NPT |
Pipe tap side inch | 1/2 NPT |
Deep Hole Guidelines | Yes |
Type of Product | Replaceable Drill Body |
Product Application | General Purpose |
