Series | Y |
Minimum diameter inch | 0.3740 |
Maximum diameter inch | 0.4369 |
Length Type | Extended |
Flute Type | Straight |
Overall length inch | 9.437 |
Tool Reference Length inch | 6.589 |
Body length inch | 5.156 |
Drill depth inch | 4.200 |
Shank type | Morse Taper |
Shank diameter inch | #2 MT |
Pipe tap side inch | 1/16 NPT |
Deep Hole Guidelines | Yes |
Type of Product | Replaceable Drill Body |
Product Application | General Purpose |
