Series | Z |
Minimum diameter inch | 0.4370 |
Maximum diameter inch | 0.5109 |
Length Type | Extended |
Flute Type | Straight |
Overall length inch | 7.561 |
Tool Reference Length inch | 5.621 |
Body length inch | 5.531 |
Drill depth inch | 4.267 |
Shank type | Flanged |
Shank diameter inch | 3/4 |
Shank length inch | 2.030 |
Pipe tap rear inch | 1/8 NPT |
Deep Hole Guidelines | Yes |
Type of Product | Replaceable Drill Body |
Product Application | General Purpose |
