26000H-20FM
#0 TA LONG HLDR METR ST SHK
T-A® Holder






Product Specifications
Series0
Minimum diameter mm12.98
Maximum diameter mm17.67
Length TypeLong
Flute TypeHelical
Overall length mm256.39
Tool Reference Length mm209.09
Body length mm206.38
Drill depth mm190.17
Shank typeFlanged
Shank diameter mm20
Shank length mm50.0
Pipe tap rear inch1/8
Pipe tap rear mm1/8 BSPT
Deep Hole GuidelinesYes
Type of ProductReplaceable Drill Body
Product ApplicationGeneral Purpose
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.62
CategoryStocked
