Series | 4 |
Minimum diameter inch | 1.8500 |
Maximum diameter inch | 2.5709 |
Length Type | 3XL |
Flute Type | Straight |
Overall length inch | 40.000 |
Tool Reference Length inch | 36.187 |
Body length inch | 36.000 |
Drill depth inch | 34.418 |
Shank type | Lathe |
Shank diameter inch | 1-1/2 |
Shank length inch | 4.000 |
Pipe tap rear inch | 1/4 NPT |
Pipe tap side inch | 1/4 NPT |
Deep Hole Guidelines | Yes |
Type of Product | Replaceable Drill Body |
Product Application | General Purpose |
