29070S-005M
#7 METRIC TA EXT 3XL HLDR 5MT
T-A® Holder






Product Specifications
Series7
Minimum diameter mm89.10
Maximum diameter mm114.48
Length Type3XL
Flute TypeStraight
Overall length mm1208.07
Tool Reference Length mm1065.20
Body length mm993.78
Drill depth mm945.52
Shank typeMorse Taper
Shank diameter mm#5 MT ISO
Pipe tap side inch1/2
Pipe tap side mm1/2 BSPT
Deep Hole GuidelinesYes
Type of ProductReplaceable Drill Body
Product ApplicationGeneral Purpose
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)76.41
CategoryStocked
