60129H-32FM
29MM STUB GEN3SYS HLD 32MM FLG
GEN3SYS® Holder






Product Specifications
Type of ProductReplaceable Drill Body
Series29
Minimum diameter inch1.1417
Minimum diameter mm29
Maximum diameter inch1.2597
Maximum diameter mm31.99
Drill depth mm35
Body length mm75.2
Overall length mm135.2
Shank diameter mm32
Shank length mm60
Shank typeFlanged
Tool Reference Length mm78.2
Flute TypeHelical
Length Type1xD
FlatYes
Coolant Inlet Style RearTSC
Pipe tap rear mm1/4 (BSP)
Deep Hole GuidelinesNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)1.38
CategoryStocked
