60320H-100C
20MM 3X GEN3SYS HLD 1" CYL
GEN3SYS® Holder






Product Specifications
Type of ProductReplaceable Drill Body
Series20
Minimum diameter inch0.7874
Minimum diameter mm20
Maximum diameter inch0.8660
Maximum diameter mm21.99
Drill depth inch2-17/32
Body length inch3-61/64
Overall length inch6-15/64
Shank diameter inch1
Shank typeFlanged
Flute TypeHelical
Length Type3xD
FlatNo
Coolant Inlet Style RearTSC
Pipe tap rear inch1/8 (NPT)
Shank length inch2-9/32
Tool Reference Length inch4-3/64
Deep Hole GuidelinesNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.91
CategoryStocked
