| Type of Product | Replaceable Drill Body |
| Series | 32 |
| Minimum diameter inch | 1.2598 |
| Minimum diameter mm | 32 |
| Maximum diameter inch | 1.378 |
| Maximum diameter mm | 35 |
| Drill depth inch | 4-9/64 |
| Body length inch | 6-29/64 |
| Overall length inch | 8-57/64 |
| Shank diameter inch | 1-1/2 |
| Shank type | Flanged |
| Flute Type | Helical |
| Length Type | 3xD |
| Flat | No |
| Coolant Inlet Style Rear | TSC |
| Pipe tap rear inch | 1/4 (NPT) |
| Shank length inch | 2-11/16 |
| Tool Reference Length inch | 6-11/32 |
| Deep Hole Guidelines | No |
