60732H-40CM
32MM 7X GEN3SYS HLD 40MM CYL
GEN3SYS® Holder






Product Specifications
Type of ProductReplaceable Drill Body
Series32
Minimum diameter inch1.2598
Minimum diameter mm32
Maximum diameter inch1.378
Maximum diameter mm35
Drill depth mm244.9
Body length mm297.7
Overall length mm367.7
Shank diameter mm40
Shank length mm70
Shank typeFlanged
Tool Reference Length mm301.3
Flute TypeHelical
Length Type7xD
FlatNo
Coolant Inlet Style RearTSC
Deep Hole GuidelinesNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)4.24
CategoryStocked
