HTA3C12-40CM
3-C TA PRO HLD 12XD 40MM CYL
T-A Pro® Holder





See Additional Technical Information

Product Specifications
Series3
Sub-SeriesC
Minimum diameter mm41.00
Maximum diameter mm47.80
Length Type12xD
Flute TypeStraight
Overall length mm619.9
Tool Reference Length mm554.7
Body length mm549.9
Drill depth mm493.2
Shank typeCylindrical
Shank diameter mm40
Shank length mm70.0
Deep Hole GuidelinesYes
Type of ProductReplaceable Drill Body
Product ApplicationHigh Performance


Related Items
7514-IP20-1     (Qty: 0)
Replacement T-A® Screw
3-4 KIT (1) TORX PLUS,CL 4H
8IP-20     (Qty: 0)
T-A® Screw Driver
DRIVER, TORX PLUS HAND IP-20
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)9.64
CategoryStocked
