| Series | 16 |
| Minimum diameter inch | 0.6299 |
| Maximum diameter inch | 0.6692 |
| Length Type | 12xD |
| Flute Type | Straight |
| Overall length inch | 11-11/16 |
| Tool Reference Length inch | 9-21/64 |
| Body length inch | 9.221 |
| Drill depth inch | 8-1/32 |
| Shank type | Cylindrical |
| Shank diameter inch | 3/4 |
| Shank length inch | 2-1/32 |
| Deep Hole Guidelines | Yes |
| Type of Product | Replaceable Drill Body |
| Product Application | High Performance |
