R36X35-40M
2.0-2.2 Revolution 3.5D 40mmSS
Revolution Drill® Holder






Product Specifications
Type of ProductIndexable Drill Body
SeriesR36
Minimum diameter mm50.8
Maximum diameter mm55.9
Drill depth mm195.8
Overall length mm289.4
Shank diameter mm40
Shank length mm70
Quantity of Inserts4
Insert prefixOP-05T308-
Shank typeStraight
CoolantYes
Coolant Inlet Style RearThrough the Shank
Flute TypeStraight
FlatYes
Gage length mm219.4
Length Type3.5 X D
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)6.04
CategoryStocked
