R48X25-CV50
3.0-3.2 Revolution 2.5D CV50
Revolution Drill® Holder






Product Specifications
Type of ProductIndexable Drill Body
SeriesR48
Minimum diameter inch3.00
Maximum diameter inch3.20
Drill depth inch7-29/32
Quantity of Inserts6
Insert prefixOP-05T308-
Shank typeCV 50
CoolantYes
Coolant Inlet Style RearThrough the Shank
Flute TypeStraight
Gage length inch10-41/64
Length Type2.5 X D
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)18.04
CategoryStocked
