R52X10-50M
3.2-3.4 Revolution 1.0D 50mmSS
Revolution Drill® Holder






Product Specifications
Type of ProductIndexable Drill Body
SeriesR52
Minimum diameter mm81.3
Maximum diameter mm86.4
Drill depth mm86.7
Overall length mm207.2
Shank diameter mm50
Shank length mm80
Quantity of Inserts6
Insert prefixOP-05T308-
Shank typeStraight
CoolantYes
Coolant Inlet Style RearThrough the Shank
Flute TypeStraight
FlatYes
Gage length mm127.2
Length Type1.0 X D
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)9.06
CategoryStocked
