SP48X10-CV50
3.0-3.2 Rev. 1.0D CV50 SP
Revolution Drill® Holder






Product Specifications
Type of ProductIndexable Drill Body
SeriesR48
Minimum diameter inch3.00
Maximum diameter inch3.20
Drill depth inch3-15/64
Quantity of Inserts4
Insert prefixOP-05T308-
Shank typeCV 50
CoolantYes
Coolant Inlet Style RearThrough the Shank
Flute TypeStraight
Gage length inch5-31/32
Length Type1.0 X D


Related Items
8mm Hex Key     (Qty: 0)
Mounting Screw Driver
8T-9     (Qty: 0)
IC Insert Screw Driver
DRIVER, TORX HAND T-9
AS-18T9-1     (Qty: 0)
Replacement Adjusting Screw
REV DRILL ADJUST. SCREW
IS-10-1     (Qty: 0)
Replacement IC Insert Screw
OP DRILL INSERT SCREW
MS-21M-1     (Qty: 0)
Replacement Mounting Screw
REV MOUNTING DRILL SCREW
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)12.38
CategoryStocked
