TM07364-3T2X
3T UN 64 2XD 1/4 SHK
AccuThread® T3






Product Specifications
Thread StyleInternal/External
Depth to Diameter2X
Weldon FlatNo
MaterialCarbide
Shank diameter inch0.25
Pitch64
Overall length inch2.5
Number of Flutes3
CoatingAM210®
Shank typeCylindrical
Type of ProductSolid Carbide Threadmill
Minimum Thread Size#1
Length of cut inch0.15
Flute TypeHelical
Cutting directionLeft Hand (M04)
Thread StandardUN
Cutter Diameter inch0.055
Coolant ThroughNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.06
CategoryStocked
