TM07364M-3T2X
3T UN 64 2XD 6MM SHK
AccuThread® T3






Product Specifications
Thread StyleInternal/External
Depth to Diameter2X
Weldon FlatNo
MaterialCarbide
Overall length mm63.00
Pitch64
Number of Flutes3
CoatingAM210®
Shank typeCylindrical
Type of ProductSolid Carbide Threadmill
Minimum Thread Size#1
Cutter Diameter mm1.40
Length of cut mm3.81
Shank diameter mm6.00
Flute TypeHelical
Cutting directionLeft Hand (M04)
Thread StandardUN
Coolant ThroughNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.05
CategoryStocked
