TM10150M-3T3X
3T ISO 1.50 3XD 8MM SHK
AccuThread® T3






Product Specifications
Thread StyleInternal/External
Depth to Diameter3X
Weldon FlatNo
MaterialCarbide
Overall length mm64.00
Pitch1.50
Number of Flutes4
CoatingAM210®
Shank typeCylindrical
Type of ProductSolid Carbide Threadmill
Minimum Thread SizeM10
Cutter Diameter mm7.80
Length of cut mm28.40
Shank diameter mm8.00
Flute TypeHelical
Cutting directionLeft Hand (M04)
Thread StandardISO
Coolant ThroughNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.08
CategoryStocked
