TM14150M-3T2X
3T ISO 1.5 2XD 10MM SHK
AccuThread® T3






Product Specifications
Thread StyleInternal/External
Depth to Diameter2X
Weldon FlatNo
MaterialCarbide
Overall length mm88.9
Pitch1.5
Number of Flutes4
CoatingAM210®
Shank typeCylindrical
Type of ProductSolid Carbide Threadmill
Minimum Thread SizeM14
Cutter Diameter mm9.4
Length of cut mm27.94
Shank diameter mm10
Flute TypeHelical
Cutting directionLeft Hand (M04)
Thread StandardISO
Coolant ThroughNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.19
CategoryStocked
