TM20250M-3T2X
3T ISO 2.5 2XD 16MM SHK
AccuThread® T3






Especificaciones del producto
Thread StyleInternal/External
Depth to Diameter2X
Weldon FlatNo
MaterialCarbide
Overall length mm100
Pitch2.5
Number of Flutes4
CoatingAM210®
Shank typeCylindrical
Type of ProductSolid Carbide Threadmill
Minimum Thread SizeM20
Cutter Diameter mm14.99
Length of cut mm39.88
Shank diameter mm16
Flute TypeHelical
Cutting directionLeft Hand (M04)
Thread StandardISO
Coolant ThroughNo
Solicitar información
Cantidad del paquete1
Cantidad mínima a ordenar1
Peso en Libras (cada uno)0.53
CategoríaEn existencias
