TM75016M-3T2X
3T UN 16 2XD 12MM SHK
AccuThread® T3






Product Specifications
Thread StyleInternal/External
Depth to Diameter2X
Weldon FlatNo
MaterialCarbide
Overall length mm88.9
Pitch16
Number of Flutes4
CoatingAM210®
Shank typeCylindrical
Type of ProductSolid Carbide Threadmill
Minimum Thread Size3/4"
Cutter Diameter mm11.938
Length of cut mm38.1
Shank diameter mm12
Flute TypeHelical
Cutting directionLeft Hand (M04)
Thread StandardUN
Coolant ThroughNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.28
CategoryStocked
