TMNK1000-NPTFM
NPTF 4F 15.7MM28.7MM AM210 M/S
AccuThread® 856 Solid






Product Specifications
Type of ProductSolid Carbide Threadmill
Overall length mm93
Shank diameter mm16
Shank typeCylindrical
CoatingAM210®
MaterialCarbide
Flute TypeHelical
Thread StandardNPTF
Minimum Thread Size1"
Pitch11.5
Number of Flutes4
Thread StyleInternal/External
Cutter Diameter mm15.75
Length of cut mm28.75
Weldon FlatNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.48
CategoryStocked
