TMNK2500-NPTFM
NPTF 5F 19.7MM38.1MM AM210 M/S
AccuThread® 856 Solid






Product Specifications
Type of ProductSolid Carbide Threadmill
Overall length mm115
Shank diameter mm20
Shank typeCylindrical
CoatingAM210®
MaterialCarbide
Flute TypeHelical
Thread StandardNPTF
Minimum Thread Size2-1/2"
Pitch8
Number of Flutes5
Thread StyleInternal/External
Cutter Diameter mm19.75
Length of cut mm38.1
Weldon FlatNo
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.91
CategoryStocked
