| Type of Product | Replaceable Drill Body |
| Series | 0 |
| Minimum diameter inch | 33/64 |
| Maximum diameter inch | 11/16 |
| Drill depth inch | 2-1/2 |
| Body length inch | 3-5/16 |
| Overall length inch | 7-19/32 |
| Shank diameter inch | #2 MT |
| Pipe tap side inch | 1/16 |
| Shank type | Morse Taper |
| Tool Reference Length inch | 4-49/64 |
| Flute Type | Helical |
| Length Type | Standard |
| Deep Hole | No |
