Series | 0 |
Minimum diameter inch | 0.5110 |
Maximum diameter inch | 0.6959 |
Length Type | Long |
Flute Type | Helical |
Overall length inch | 12.094 |
Tool Reference Length inch | 9.263 |
Body length inch | 7.813 |
Drill depth inch | 7.409 |
Shank type | Morse Taper |
Shank diameter inch | #2 MT |
Pipe tap side inch | 1/16 NPT |
Deep Hole Guidelines | Yes |
Type of Product | Replaceable Drill Body |
Product Application | General Purpose |
