465004
BAL 3E 1.496"-1.97" MVS32-18
Wohlhaupter® Boring Head






Product Specifications
Type of ProductBoring Head
Minimum diameter mm38
Minimum diameter inch1.496
Maximum diameter mm50
Maximum diameter inch1.97
Working length mm66.00
Working length inch2.598
Body length mm64
Body length inch2.5
Body Diameter mm34
Body Diameter inch1.339
Male minor18
Male major32
Adjustment dial inch0.0001
Adjustment TypeDigital
Digital Component3ETech (external)
Adjustment UnitImperial
Offset mm12
Offset inch0.474
MaterialSteel
Ordering Information
Package Qty1
Min. Order Qty1
Weight in lbs (each)0.882
CategoryStocked
