| Series | A |
| Minimum diameter inch | 0.9688 |
| Maximum diameter inch | 1.3750 |
| Length Type | Short |
| Flute Type | Straight |
| Overall length inch | 6.500 |
| Tool Reference Length inch | 3.531 |
| HP Reference Length inch | 3.250 |
| Body length inch | 3.000 |
| Drill depth inch | 1.966 |
| Shank type | Lathe |
| Shank diameter inch | 1 |
| Shank length inch | 3.500 |
| Coolant | No Coolant |
| Deep Hole Guidelines | No |
| Type of Product | Replaceable Drill Body |
| Product Application | General Purpose |
