| Series | E |
| Minimum diameter inch | 2.5000 |
| Maximum diameter inch | 3.3750 |
| Length Type | Short |
| Flute Type | Straight |
| Overall length inch | 9.875 |
| Tool Reference Length inch | 6.313 |
| HP Reference Length inch | 5.781 |
| Body length inch | 5.000 |
| Drill depth inch | 5.500 |
| Shank type | Morse Taper |
| Shank diameter inch | #4 MT |
| Shank length inch | 4-7/8 |
| Coolant | No Coolant |
| Deep Hole Guidelines | No |
| Type of Product | Replaceable Drill Body |
| Product Application | General Purpose |
